SPE Vacuum Manifold System NMFP-100 is designed with 24 ports for enhanced efficiency in sample processing. It enables precise flow rate control with independently adjustable valves for consistent operation. The pump has an ultimate pressure range of 0.01 to 0.085 MPa for optimal performance. It features a quartz glass vacuum chamber with PTFE components for durability and chemical resistance. This unit is compatible with a large-capacity collector for rapid mass sample concentration.
$2,100.00
Specifications
| Number of Ports | 24 |
| Lid Material | Polyoxymethylene |
| Vacuum Chamber Material | Quartz glass |
| Pressure Resistance | -80 Kpa |
| Stable Pressure Range | 0 to 80 Kpa |
| Test Tubes | ≤ 105 mm, Φ10/Φ13/Φ15 |
| Ultimate Pump Pressure | 0.01 to 0.085 MPa |
| Maximum Pump Flow rate | 5 to 30 L/min |
| Power Consumption | 90 W |
| Power Supply | AC 220 V, 50/60 Hz |
| Dimensions | 825 × 472 × 610 mm |
| Pump Weight | 3.8 Kg |
| Net Weight | 12 kg |
| Gross Weight | 12.5kg |
Features
Applications
Standard Accessories
Individual flow valveOptional Accessories
Drainage catheter × 5pcs /packAsk Expert
Labnics SPE Vacuum Manifold Systems are designed for efficient sample processing with multiple ports and precise flow control. They feature quartz glass vacuum chambers with PTFE components, offering durability and chemical resistance. They feature an adjustable test tube rack height to accommodate various sample sizes. Our units ensure stable flow rates for consistent and efficient operation.
