Temperature and Humidity Test Chamber NTHC-200

Temperature and Humidity Test Chamber NTHC-200 is designed for precision testing of material resilience. It tests the samples under higher temperature and humidity conditions. Crafted from corrosion-resistant stainless steel, ensuring durability and reliability. Its robust construction not only safeguards the chamber but also guarantees consistent performance over extended periods.

---

$16,538.00

Buy Now Catalog

Specifications

Capacity	100 L
Temperature range	(-20) ℃ to 150 ℃, (-40) ℃ to 150 ℃, (-70 ) ℃ to 150 ℃
Temperature cooling rate	1 ℃ / min
Temperature heating rate	3 ℃ / min
Temperature fluctuations	± 0.5 ℃
Temperature deviation	± 2.0 ℃
Humidity range	20 % to 98 % R.H
Humidity deviation	± 2.5 % RH
High temperature	180 ℃
Lowest humidity	10 % RH
Internal dimension (D × W × H)	400 × 500 × 500 mm
Overall dimension (D × W × H)	860 × 1050 × 1620 mm

Features

• Toughened double layered glass window for observation
• Independent R & D software to easily control, and monitor the chamber
• Controls humidity with capacitive humidity sensor
• LCD touch screen controller with graphic display
• Thermal insulating material resistant to high temperature and density
• Windows with anti-sweat heaters to prevent condensation and droplets
• Heat-resistant material with high temperature resistance and density
• Unit turns off after alarm for over heating
• Compressor overload switch

Applications

• Temperature and Humidity Test Chamber is widely used in basic and advanced research, pharmaceutical industries, chemical industries, food and beverage.
